Replaced side marker bulb

Other night I noticed my back driver side marker light wasn't lit. Today, since HHR was clean, was 55 degrees, and was sunny her, I decided to check the other lights and replace the burnt out one. I found out that the front driver side marker was also not lit Pulled off other side marker on back and put in driver side. Luckily it worked and wasn't an electrical issue. Got them both burnt out bulbs replaced and want to give thanks to Applenut for the tips on the silver star replacement thread. Only took me minutes to replace them. Has anyone else had to replaced the side marker bulbs yet?
shaginwgn is offline   Reply With Quote
Old 03-13-2008, 05:02 PM   #2
jx3
Senior Member

jx3's Avatar

Join Date: 10-19-2005
Location: Miami
Posts: 20,746
Images: 247
Quote:
Originally Posted by shaginwgn View Post
Other night I noticed my back driver side marker light wasn't lit. Today, since HHR was clean, was 55 degrees, and was sunny her, I decided to check the other lights and replace the burnt out one. I found out that the front driver side marker was also not lit Pulled off other side marker on back and put in driver side. Luckily it worked and wasn't an electrical issue. Got them both burnt out bulbs replaced and want to give thanks to Applenut for the tips on the silver star replacement thread. Only took me minutes to replace them. Has anyone else had to replaced the side marker bulbs yet?
I've got a front sidemarker that doesn't light up, I've been meaning to do this for a couple of weeks. Thanks for the reminder!
jx3 is offline   Reply With Quote
Old 03-13-2008, 05:30 PM   #3
Senior Member
Thread Starter

shaginwgn's Avatar

Join Date: 06-24-2006
Location: Bowling Green, OH
Posts: 2,316
Images: 164
Quote:
Originally Posted by jx3 View Post
I've got a front sidemarker that doesn't light up, I've been meaning to do this for a couple of weeks. Thanks for the reminder!
bulb number 194 or 194LL(long life) or 194na(yellow). On the front after releasing clip on bulb holder and wire, you have to give it a slight twist left to get bulb and bulb holder as it has a small thread like system to hold it in place
shaginwgn is offline   Reply With Quote
Old 02-03-2010, 08:31 PM   #4
Senior Member

Join Date: 01-21-2010
Location: The Middie OHIO
Posts: 1,717
Images: 128
Both my passenger side markers were out. Got the back one out easy since there was a screw holding it in...how do you get the front passenger corner lens out?? I'm really hoping you all aren't going to tell me that I have to pull out the fender liner...
SmootHHR is offline   Reply With Quote
Old 02-03-2010, 08:38 PM   #5
Senior Member

Join Date: 11-11-2008
Location: East Brunswick, NJ
Posts: 273
Images: 26
Quote:
Originally Posted by SmootHHR View Post
I'm really hoping you all aren't going to tell me that I have to pull out the fender liner...
BINGO!!!

Sorry...it's easy, once you get the liner off.
roofer1976 is offline   Reply With Quote
Old 02-03-2010, 08:40 PM   #6
Senior Member

Join Date: 01-21-2010
Location: The Middie OHIO
Posts: 1,717
Images: 128
Well crap..................guess I'm not doing that tonight Thanks for the input though
SmootHHR is offline   Reply With Quote
Old 02-03-2010, 09:25 PM   #7
Senior Member

Join Date: 06-07-2009
Location: Mt. Sterling, Kentucky
Posts: 108
I have a couple of side markers out as well but I think it was from when I removed the markers to tint
Saltine is offline   Reply With Quote
Old 02-04-2010, 07:28 AM   #8
Senior Member

Join Date: 01-21-2010
Location: The Middie OHIO
Posts: 1,717
Images: 128
I ended up doing it last night anyway...I couldn't stop thinking about that stupid light! And yes roofer, it was really easy once I got the liner loose.

Saltine, I'd love to see some pics of the tinted lens'. On one of my SHO's I had the tail lights sprayed and they looked AWESOME! You could still see the reflectors when lights hit them but they looked black as night during the day. 90% Clear, 10% PPG Onyx Black, 3.5ish coats
SmootHHR is offline   Reply With Quote
Old 02-04-2010, 07:34 AM   #9
Senior Member

Join Date: 06-19-2008
Location: Indiana
Posts: 1,492
Images: 16
Quote:
Originally Posted by SmootHHR View Post
I ended up doing it last night anyway...I couldn't stop thinking about that stupid light! And yes roofer, it was really easy once I got the liner loose.

Saltine, I'd love to see some pics of the tinted lens'. On one of my SHO's I had the tail lights sprayed and they looked AWESOME! You could still see the reflectors when lights hit them but they looked black as night during the day. 90% Clear, 10% PPG Onyx Black, 3.5ish coats
one of these days when it's clean i'll take a couple hots of mine too. I just took window tint and wrapped the reflectors in it. Once installed they look fantastic, they still reflect but blend right in with the vehicle. If I ever need to go back to stock, i can just remove the tint.
twistrman is offline   Reply With Quote
Old 06-01-2012, 10:09 PM   #10

Join Date: 09-26-2011
Location: NASH CREEK,NEW BRUNSWICK,CANADA
Posts: 1
Quote:
Originally Posted by shaginwgn View Post
bulb number 194 or 194LL(long life) or 194na(yellow). On the front after releasing clip on bulb holder and wire, you have to give it a slight twist left to get bulb and bulb holder as it has a small thread like system to hold it in place
On my 2008 HHR the rear side light was just a simple push in bulb ...while the front requires a 2 pronged bulb.
